新輔科技, Nutek Material,長期提供之晶體,晶圓片,基板,Crystals,Wafers,Substrates:

矽(Si)晶圓片,Sapphire Wafer,Al2O3,藍寶石晶圓片,SrTiO3_Single Crystal_Wafers and Substrates_氧化鍶鈦_單晶晶片及基板,II-VI Group Wafer, 二六族化合物晶圓片,Glass / Ceramic Substrates,玻璃及陶瓷基板,Quartz,SiO2/SiC/SrTiO3 Wafer,石英/碳化矽/氧化鍶鈦晶圓片, Germanium /MgO Wafer,鍺 Ge/氧化鎂 晶片,Single Crystal Substrates,單晶基板

Go to ⇒ SiC_Wafers and Substrates_碳化矽_晶片及基板

SrTiO3_Single Crystal_Wafers and Substrates_氧化鍶鈦_單晶晶片及基板

SrTiO3_Single Crystal_Wafers and Substrates_氧化鍶鈦_單晶晶片及基板

Wafer Size: 1 inch./2 inch./3 inch./4 inch.
Substrate Size: 5 x 5 mm/10 x 10mm /20 x 20 mm
Thickness 0.5 mm /0.8mm/1.0 mm
Growth method Flame fusion / Verneuil  method
Crystal Orientation/Structure Tolerance of orientation :+/- 0.5 ° / Cubic:<100> , <111> , <110>
Dielectric/Lattice Constant 300 /3.905 A
Surface SSP/DSP_Ra: no more than 10 A
SrTiO3 Nb doped 1.0 %wt Resistivity:0.0035 / Mobility: 9.0
SrTiO3 Nb doped 0.7%wt Resistivity:0.007/ Mobility: 8.5
SrTiO3 Nb doped 0.4 %wt Resistivity:0.05 / Mobility: 6.5
SrTiO3 Nb doped 0.1 %wt Resistivity:0.08 / Mobility: 6.5
