標準規格 Standard Specification Silicon Wafers 矽(Si)晶片長備庫存

新輔科技 Nutek Materials 可以提供有關矽晶片之產品及服務:
Standard_Specification-Si Wafer_標準規格-矽晶片, Non-Standard_Specification-Si Wafer_非標準規格_矽晶片
Special_Specification-Si Wafer_特殊規格_矽晶片 Custom Films, 鍍膜服務片, Ultra Flat, Intrinsic_Silicon Wafer, Ultra Thin_Silicon Wafer, Epi_Silicon Wafer, Ultra-Thick_Silicon Wafer, Thermal-Oxide_Silicon Wafer, Special-Orientation_Silicon Wafer, Silicon Nitride ( Si3N4 ) Silicon Wafer, Heavily Doped Wafer Silicon Wafer,SOI ( Silicon-on-Insulator)Silicon Wafer, Off Axis Orientation Silicon Wafer, High Resistivity Silicon Wafer.

160: 100mm, N type, Phos, <100> ON, 0.8 – 1.2 ohm-cm, 525um +/- 20, TTV <5um, Prime

161: 100mm, N type, Phos, <100> ON, 0.8 – 1.2 ohm-cm, 525um +/- 25, TTV <10um, Prime

162: 100mm, N type, Phos, <100> ON, 1-10 ohm-cm, 525um +/- 20, TTV <5um, Single SEMI Flat,Prime

163: 100mm, N type, Phos, <100> ON, 1-10 ohm cm, 525um-50, TTV <15um, Test

164: 100mm, N Type, Phos, <100> ON, 1-20 ohm-cm, 525um +/- 50, TTV <15, Single SEMI Flat, Test

165: 100mm, N Type, Phos, <100> ON, 1-40 ohm-cm, 525um +/- 50, TTV <15, Single Flat, 3 PartCassette

166: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 381um +/- 20, TTV <5um, Prime

◊4" Si wafer 第◊ 1 ◊ 2◊ 3◊ 4◊ 5◊ 6◊ 7◊ 8◊ 9◊ 10◊ 11◊ 12◊ 頁;

167: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 381um +/- 25, TTV <10um, Prime

168: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 525um +/- 20, TTV <5um, Single SEMI Flat,Prime

169: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 525um +/- 20, TTV <5um, Prime

170: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 525um +/- 25, TTV <10um, Single SEMI Flat,Prime

171: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 525um +/- 25, TTV <10um, Prime

172: 100mm, N type, Phos, <100> ON, 1-5 ohm-cm, 525um +/- 50, TTV <15um, 2 Part Cassette, Test

173: 100mm, N type, Phos, <100>, 10-20 ohm cm, 300um +/- 25, TTV <10um Single Side Polished,Semi

◊ 2"◊ 3"◊ 4"◊ 5"◊ 6"◊ 8"◊ Si wafer
