Growth method Czochralski
Crystal structure Cubic
Wafer Size 2 inch./3 inch./ 4 inch.
Orientation <100> , <111> , <110> , or others
Off orientation Off:  2° to  10°
Conductivity type P - type / N - type
Dopant Materials Antimony / Gallium /Undoped
Resistivity range N type : <=0.4 ohm-cm /P type : 0.005 ~ 30 ohm-cm /Undoped : >=30 ohm-cm
Thickness 0.5 mm
Surface SSP/DSP/EPD= 5000 or <= 10000 cm-2
