Alumina_Al2O3-99.6%_Ceramics Substrates

新輔科技, Nutek Material,長期提供之晶體,晶圓片,基板,Crystals,Wafers,Substrates:

矽(Si)晶圓片,Sapphire Wafer,Al2O3,藍寶石晶圓片,Alumina_Al2O3-99.6%_Ceramics Substrates_陶瓷基板,II-VI Group Wafer, 二六族化合物晶圓片,Glass / Ceramic Substrates,玻璃及陶瓷基板,Quartz,SiO2/SiC/SrTiO3 Wafer,石英/碳化矽/氧化鍶鈦晶圓片, Germanium /MgO Wafer,鍺 Ge/氧化鎂晶片,Single Crystal Substrates,單晶基板

Alumina_Al2O3-99.6%_Ceramics Substrates_陶瓷基板

Ceramics Type	Alumina ,Al2O3-96%	Alumina,Al2O3-99.6%	Aluminium Nitride , AlN	Zirconia, ZrO2
Wafer Size	1 to 8 inch.	1 to 8 inch.	1 to 8 inch.	1 to 8 inch.
Substrate Size	10 x 10 / 25 x 25mm 50 x 50/75x75mm 100 x 100 mm	10 x 10 / 25 x 25mm 50 x 50/75x75mm 100 x 100 mm	10 x 10 / 25 x 25mm 50 x 50/75x75mm 100 x 100 mm	10 x 10 / 25 x 25mm 50 x 50/75x75mm 100 x 100 mm
Thickness	0.4 / 0.5 /0.8/ 1 .0mm 1.5/2 /2.2mm	0.4 / 0.5 /0.8/ 1 .0mm 1.5/2 /2.2mm	0.4 / 0.5 /0.8/ 1 .0mm 1.5/2 /2.2mm	0.4 / 0.5 /0.8/ 1 .0mm 1.5/2 /2.2mm
Surface	As burned SSP/DSP Ra no more than 0.28um	As burned SSP/DSP Ra no more than 0.28um	As burned SSP/DSP Ra no more than 0.28um	As burned SSP/DSP Ra no more than 0.28um
Color	White	Dark-White	Dark Gray	White
Density	3.72	3.85	3.3	6.04
Thermal conductivity	22.3	29.5	160 -185	2.4
Thermal Expansion	8.0	8.2	4.6	10
Dielectric strength	14E6	18E6	14E6	19-21E6
Dielectric Constant	9.5	9.8	8.7	29
Flexural Strength	350	500	450	550

Alumina_Al2O3-99.6%_Ceramics Substrates_陶瓷基板:

Alumina_Al2O3-99.6%_Ceramics Substrates_陶瓷基板:
